DN Solutions DEM series vertical machining centre

Brand: DN SOLUTIONS

The DN SOLUTIONS DEM series is a new generation of vertical machining centres designed to combine industrial performance, precision and continuous productivity. Developed to meet the demands of modern manufacturing, it provides a stable, scalable platform for machining technical parts in intensive production environments.

Thanks to its rigid, optimised structure, the DEM series delivers excellent machining stability, high repeatability and consistent quality, even over sustained production cycles. It is a dependable solution for manufacturers looking to optimise performance while safeguarding the quality of the parts they produce.

https://www.scomo.fr/web/image/product.template/152228/image_1920?unique=a798ada

Key features and benefits

Optimised rigid structure
Provides high machining stability for consistent performance in production.

Industrial precision
Delivers reliable tolerances and excellent part repeatability.

Enhanced productivity
Optimises cycle times to raise overall manufacturing output.

Robust design
Suited to intensive use in demanding industrial environments.

Versatile machining
Suitable for a wide range of technical parts and industrial materials.

Production-line integration
Fits easily into modern manufacturing cells, automated or otherwise.

Thermal and dynamic stability
Ensures consistent quality, even over long production runs.

Industrial applications

The DN SOLUTIONS DEM series is particularly well suited to the following operations:

  • Machining of precision mechanical parts
  • Series manufacture of industrial components
  • Production of parts for the automotive and industrial equipment sectors
  • Machining of multi-purpose technical components
  • Subcontract machining
  • Manufacture of functional parts and mechanical structures

Availability and services

Machine available to order in a choice of configurations

Support with integration into your production environment

Installation and commissioning by qualified engineers

Operator training to get you up and running quickly

Responsive after-sales service and spare parts availability

Financing options available

Request information


DEM series

This high-performance vertical machining centre stands out for its exceptional reliability and advanced machining capabilities. Designed to deliver high cutting power, it also handles high-speed operations while maintaining remarkable precision.

Specifications
Models
DIMENSIONS - Height
DIMENSIONS - Length
DIMENSIONS - Weight
DIMENSIONS - Width
FEED RATES - X-Axis Rapid Traverse
FEED RATES - Y-Axis Rapid Traverse
FEED RATES - Z-Axis Rapid Traverse
MAIN SPINDLE - Max. Spindle Power
MAIN SPINDLE - Max. Spindle Speed
MAIN SPINDLE - Max. Spindle Torque
MAIN SPINDLE - Tool Taper
TABLE - Maximum Workpiece weight
TABLE - Table Length
TABLE - Table Width
TRAVELS - X-Axis Travel Distance
TRAVELS - Y-Axis Travel Distance
TRAVELS - Z-Axis Travel Distance
DEM 4000
2317 mm
1875 mm
3100 kg
2200 mm
24 m/min
24 m/min
24 m/min
5.5/7.5 kW
8000 r/min
47.7 N·m
ISO #40
400 kg
650 mm
400 mm
550 mm
400 mm
450 mm
