Band saw IMET BS 300 PLUS SHI
Brand: IMET
Model: GBS 242 GH
Reference: T25073
| Saw type: | Gravity-operated |
| Mitre cutting: | Yes |
| Capacity at 90°: round/square/rectangular (W x H): | 250 mm / 210 mm / 290x210 mm |
| Capacity at +45°: round/square/rectangular (W x H): | 220 mm / 200 mm / 210x200 mm |
| Capacity at -45°: round/square/rectangular (W x H): | 170 mm / 170 mm / 170x170 mm |
| Capacity at +60°: round/square/rectangular (W x H): | 140 mm / 130 mm / 140x130 mm |
| Blade dimensions: | 2965 x 27 x 0,9 mm |
| Machine dimensions (L x W x H): | 1500 x 1250 x 1700 mm |
| Total installed power: | 1,1 / 1,3 kW |
| Machine weight: | 290 KG |
The GBS 242 GH is IMET's controlled-descent band saw. Versatile and easy to use, the GBS 242 GH is ideal for maintenance work and for light and medium structural steelwork. For mitre cuts up to 45° to the right and 60° to the left.
Internal Reference:
T25073
