DN Solutions HFP 1540 series 5-axis machining centre

Brand: DN SOLUTIONS

The HFP 1540 series from DN SOLUTIONS is designed for 5-axis profiling operations that call for high precision, high dynamics and advanced structural stability. It meets the demands of industries where complex shapes and finish quality are essential.

Developed for machining technical parts and complex surfaces, the HFP 1540 series optimises toolpaths while ensuring excellent repeatability, high multi-axis accuracy and consistent surface finish. A high-performance solution for demanding, specialised production environments.

https://www.scomo.fr/web/image/product.template/152246/image_1920?unique=92d01d6

Key features and benefits

5-axis profile machining
Produces complex shapes with high kinematic accuracy.

Highly dynamic machining
Optimises movements for smoother, better-quality cutting.

Multi-axis precision
Holds tight tolerances on complex engineering parts.

High-quality finish
Delivers consistent surfaces suited to demanding applications.

Rigid, stable structure
Reduces vibration for precise, controlled machining.

Optimised productivity
Cuts cycle times through efficient toolpath management.

Industrial reliability
Designed for continuous operation in demanding production environments.

Industrial applications

The DN SOLUTIONS HFP 1540 series is particularly well suited to the following operations:

  • 5-axis machining of complex surfaces
  • Profiling of engineering parts and special structures
  • Manufacture of aerospace and industrial components
  • Machining of parts with complex geometries
  • Production of high-precision parts
  • Specialist subcontract machining

Availability and services

Machine available to order in a range of configurations

Support with integration into your production environment

Installation and commissioning by qualified engineers

Operator training to get you up and running quickly

Responsive after-sales service and spare parts availability

Financing options available

Request information


Request information Download data sheet Download
manufacturer docs
Contact Us

HFP 1540 series

The HFP 1540 was designed for high-speed machining of some of the largest aluminium structural parts. From the very first part it produces, it transforms your 5-axis machining capacity for aerospace, delivering immediate gains in efficiency and performance. This machine is ideal for demanding applications that require precision, speed and productivity on large components.

Specifications
Models
DIMENSIONS - Height
DIMENSIONS - Length
DIMENSIONS - Weight
DIMENSIONS - Width
FEED RATES - X-Axis Rapid Traverse
FEED RATES - Y-Axis Rapid Traverse
FEED RATES - Z-Axis Rapid Traverse
MAIN SPINDLE - Max. Spindle Power
MAIN SPINDLE - Max. Spindle Speed
MAIN SPINDLE - Max. Spindle Torque
MAIN SPINDLE - Tool Taper
TABLE - Maximum Workpiece weight
TABLE - Table Length
TABLE - Table Width
TOOL STORAGE CAPACITY - No. of tool station
TRAVELS - X-Axis Travel Distance
TRAVELS - Y-Axis Travel Distance
TRAVELS - Z-Axis Travel Distance
HFP 1540
4250 mm
18135 mm
74200 kg
8000 mm
60 m/min
40 m/min
60 m/min
90/78.5 kW
30000 r/min
49.9/36.9 kW
HSK-A63
3000 kg
4000 mm
1500 mm
60/90/120 {90/120} ea
4200 mm
1600 mm
550 mm
